ROLAND TRUEVIS XP-640Big color.
Serious production power.
64" high-speed eco-solvent printing for shops ready to do more. Turn bold ideas into vehicle wraps, banners, retail displays, and wall graphics with the speed, detail, and color your customers expect.
Dual staggered printheads. Versatile TH inks. Included VersaWorks 7 software. Your next production upgrade starts here.
64"MAXIMUM MEDIA WIDTH
819SQ FT / HOUR - MAXIMUM*
8 COLORSEXPANDED-GAMUT OPTION
1,800 dpiMAXIMUM RESOLUTION*
*819 sq ft/hour applies to dual-CMYK billboard mode. Actual speeds vary by configuration, media, and print mode. Maximum resolution and maximum speed are achieved in different modes.
Built for your next stage of growth
More possibilities. More production potential.
The Roland TrueVIS XP-640 64" High-Speed Eco-Solvent Printer gives sign shops, wrap businesses, and commercial print providers a dedicated platform for wide-format graphics. Produce eye-catching signage, detailed photographic images, and branded environments with one versatile roll-to-roll printer.
Choose dual CMYK for higher throughput or 8-color printing for a wider color gamut. With automated setup features and integrated media take-up, the XP-640 helps keep your workflow moving from the first print to the last roll.
Color that gets noticed
Go beyond everyday CMYK.
Give brand colors and promotional graphics extra impact. The 8-color TH ink configuration adds Light Black, Orange, Green, and Red to CMYK, extending the range of colors you can reproduce.
Roland's True Rich Color settings bring together vivid solids, natural skin tones, neutral grays, and smooth gradients for graphics with depth and detail.
For color-focused work
8-color expanded gamut
CMYKLkOrGrRe
A strong fit for brand-sensitive signage, premium vehicle graphics, retail campaigns, and jobs where an expanded color range matters.
For throughput-focused work
Dual-CMYK productivity
Keep banners, promotional signage, and other production jobs moving with a configuration focused on output speed.
Up to 819 sq ft/hour in billboard mode.
Everyday operation, simplified
Smart features. Smoother workflow.
Control at your fingertips
The 7-inch color LCD touchscreen puts printer status, ink levels, and key functions within easy reach.
Keep the roll moving
Included automatic media take-up supports organized roll-to-roll output for longer production runs.
Easier output separation
Perforated sheet cutting helps simplify separation of completed graphics during finishing.
Software included
Take control of every job.
VersaWorks 7 RIP software gives your team practical tools for preparing and managing print production. Nest jobs to use media efficiently, tile large graphics, crop artwork, and manage spot colors from one workflow.
Automatic media gap adjustment helps reduce manual calibration work, while Roland DG Connect provides access to printer monitoring and maintenance information.
Build your finishing workflow
Print the next job. Cut the last one.
Pair the XP-640 with a compatible standalone cutter to build a dedicated print-and-cut workflow. While the cutter finishes one job, your printer can move on to the next.
The XP-640 is a print-only device. Contour cutting requires a separate compatible cutter, sold separately.
The details that matter
Technical specifications
| Printing method | Piezo ink-jet |
|---|
| Media width | 10.2-64 in (259-1,625 mm) |
|---|
| Maximum printing width | 63.5 in (1,615 mm) |
|---|
| Maximum media thickness | 39.3 mil (1.0 mm) with liner |
|---|
| Maximum roll diameter / weight | 9.8 in (250 mm) / 99 lb (45 kg) |
|---|
| Core diameter | 3 in (76.2 mm) or 2 in (50.8 mm) |
|---|
| Ink type | TrueVIS TH eco-solvent ink, 500 ml cartridges |
|---|
| Ink configurations | 8-color: CMYK + Light Black + Green + Orange + Red; 4-color: dual CMYK |
|---|
| Maximum print resolution | 1,800 dpi |
|---|
| Maximum advertised speed | 819 sq ft/hour in dual-CMYK billboard mode |
|---|
| Media heating system | Print heater: 86-113°F (30-45°C); dryer: 86-131°F (30-55°C) |
|---|
| Connectivity | Ethernet (100BASE-TX / 1000BASE-T) |
|---|
| Power consumption | Approx. 1,180 W during operation / 50 W in sleep mode |
|---|
| Dimensions - W x D x H | 113.7 x 29.5 x 55.8 in (2,886 x 748 x 1,415 mm) |
|---|
| Weight | 417 lb (189 kg) |
|---|
| Operating environment | 68-89.6°F (20-32°C); 35-80% RH, non-condensing |
|---|
Ready to build your setup
What's included
- Roland TrueVIS XP-640 printer and dedicated stand
- Automatic media take-up unit and media holders
- Power cord and replacement separating blade
- Maintenance cleaning liquid and drain bottle
- User documentation
- VersaWorks 7 RIP software
- Roland DG Connect software
- Roland DGA two-year limited warranty, subject to manufacturer terms
Complete your workflow
Required / sold separately
- TH ink cartridges: Required for your selected configuration.
- Compatible media: Match your substrate to the application.
- Professional installation.
- Optional high-volume dryer: Recommended for demanding production, faster modes, or heavier ink coverage.
- Optional standalone cutter: Required for contour-cut products.
Warranty eligibility requires registration within 60 days of purchase and exclusive, continuous use of Roland DGA-approved inks. See applicable manufacturer terms for full coverage and requirements. Drying and lamination timing depend on ink coverage, media, operating conditions, and the material manufacturer's recommendations.
